AISI 304 Glass Canopy Rod Connector for Tension Rod
1. Product Description AISI 304 Glass Canopy Rod Connector The connector rod connector provides a secure connection between a tension rod and the glass panel in canopy and awning support systems. Designed for architectural glass installations, this fitting helps transfer loads from the supporting rod to the glass while maintaining a clean and compact appearance. […]
1. Product Description
AISI 304 Glass Canopy Rod Connector
The connector rod connector provides a secure connection between a tension rod and the glass panel in canopy and awning support systems. Designed for architectural glass installations, this fitting helps transfer loads from the supporting rod to the glass while maintaining a clean and compact appearance.
Made from AISI 304 stainless steel, the connector offers strength and corrosion resistance for architectural applications. Its PSS polished surface provides a clean metallic finish that complements modern glass canopy structures.
The fitting is compatible with Ø16 mm tension rods and supports tempered laminated glass in 13.52 mm (6.2.6), 17.52 mm (8.2.8), and 21.52 mm (10.2.10) configurations.
2.Glass Canopy Rod Connector Features
The rod-to-glass connector provides a practical connection point between the supporting tension rod and laminated glass. Its compact stainless steel construction makes it suitable for professional canopy and awning installations.
The fitting has a maximum operating load of 4,500 N (450 kg) in the Fx direction and 3,500 N (350 kg) in the Fy direction. However, the performance of a complete canopy system also depends on the wall structure, mounting components, glass configuration, anchors, and installation method.
In addition, installers can integrate the connector with compatible canopy components to create a coordinated support structure.
3. Glass Canopy Rod Connector Applications
This glass canopy rod connector is suitable for glass and polycarbonate canopies and awnings. Typical applications include structures above shop entrances, basement entrances, smoking areas, and other architectural spaces.
Its polished stainless steel appearance makes the fitting suitable for projects where both structural support and a clean architectural finish are important.
When combined with a compatible tension rod, wall mount, and other canopy fittings, the connector forms part of a complete glass canopy support system.
4.Compatible Glass Canopy Hardware
| Specification | Details |
|---|---|
| Product Name | Glass Canopy Rod-to-Glass Connector |
| Model | 391-SS304 |
| Product Type | Rod-to-Glass Connector |
| Material | AISI 304 Stainless Steel |
| Surface Finish | PSS / Polished |
| Compatible Rod | Ø16 mm |
| Glass Type | Tempered Laminated Glass |
| Glass Thickness | 13.52 / 17.52 / 21.52 mm |
| Glass Configuration | 6.2.6 / 8.2.8 / 10.2.10 |
| Maximum Load Fx | 4,500 N (450 kg) |
| Maximum Load Fy | 3,500 N (350 kg) |
| Application | Glass & Polycarbonate Canopies / Awnings |
5. Compatible Hardware
Glass Canopy Hardware for B2B Projects
The 391-SS304 glass canopy rod connector works with compatible Ø16 mm tension rods and related wall-side mounting hardware.
For a coordinated canopy system, installers can combine the rod-to-glass connector with compatible tension rods, wall mounts, and other glass canopy hardware. Before ordering, customers should confirm the required glass thickness, rod dimensions, installation conditions, and complete system configuration.
6.B2B Project Orders
AOYU supplies architectural glass hardware for professional and project applications. Customers can provide project drawings, required quantities, glass specifications, and installation requirements when requesting a quotation.
For project orders, our team can help confirm whether the canopy rod connector and compatible canopy components match the required installation conditions.
Frequently Asked Questions
What is a glass canopy rod connector used for?
A glass canopy rod connector connects the supporting tension rod to the glass panel in a canopy or awning system. It provides a secure rod-to-glass connection for architectural glass installations.
What size tension rod is compatible with the 391-SS304 connector?
The 391-SS304 connector is compatible with Ø16 mm tension rods. Customers should confirm the rod size and complete canopy system configuration before ordering.
What glass thicknesses are compatible with this canopy connector?
The connector supports tempered laminated glass in 13.52 mm (6.2.6), 17.52 mm (8.2.8), and 21.52 mm (10.2.10) configurations.
What is the maximum load of the 391-SS304 rod-to-glass connector?
The specified maximum operating load is 4,500 N (450 kg) in the Fx direction and 3,500 N (350 kg) in the Fy direction. Overall system performance also depends on the glass, anchors, supporting hardware, and installation conditions.
Can the 391-SS304 connector be used for glass awnings?
Yes. The 391-SS304 connector is designed for glass and polycarbonate canopy and awning support systems, including installations above entrances and other architectural areas.
