90° Glass-to-Glass Connector for 2 Fixed Glass Panels

The 90° Glass-to-Glass Connector for 2 Fixed Glass Panels joins two tempered glass panels at a fixed right angle.

Its main purpose is to create a stable glass-to-glass 90-degree corner connection without using a conventional metal frame. As a result, installers can maintain a clean and minimal appearance in frameless glass systems.

The connector works with 8–12mm tempered glass and comes in SS201 or SS304 stainless steel. Standard finishes include Mirror, Satin and Matte Black, while custom colors are available for project orders.

This fitting works well in glass partitions, indoor and outdoor glass railings, stair glass panels and other architectural glass installations.

Product Specifications

Specification	Details
Product Name	90° Glass-to-Glass Connector for 2 Fixed Glass Panels
Product Type	90° Fixed Glass Connector
Connection Type	Glass-to-Glass
Connection Angle	90°
Glass Configuration	2 Fixed Glass Panels
Material	SS201 / SS304 Stainless Steel
Glass Type	Tempered Glass
Glass Thickness	8–12mm
Standard Finish	Mirror / Satin / Matte Black
Custom Colors	Available
Applications	Glass Partitions / Railings / Glass Stairs
Indoor Use	Yes
Outdoor Use	SS304 Recommended
Sample Dispatch	Within 3 Days
Customization	Available

Fixed 90° Glass Corner Connection

This 90 degree glass to glass connector holds two fixed glass panels in a right-angle configuration.

Instead of connecting glass to a wall or post, the fitting creates a direct connection between the two glass panels.

Therefore, it is especially useful at corners where two fixed panels meet.

Typical positions include:

• 90° glass partition corners
• Glass railing corners
• Staircase glass panel junctions
• Balcony glass corners
• Frameless architectural glass structures

The fixed-angle design helps installers maintain consistent alignment between both panels.

Designed for Fixed Glass Panels

This connector works specifically with stationary glass panels.

It does not function as a hinge, pivot or moving-door fitting. Instead, it supports the connection between two fixed sections of glass.

This makes the product suitable for projects where the glass needs to remain firmly positioned after installation.

For example, installers can use it to form a permanent 90° corner in a frameless glass partition.

Suitable for Glass Partitions

Glass partitions are one of the most common applications for this fitting.

The connector allows two tempered glass panels to meet at 90° while keeping the surrounding hardware relatively compact.

As a result, designers can create:

Office glass partitions
Hotel interior partitions
Retail glass dividers
Residential glass partitions

without adding a large metal corner frame.

Glass Railing and Stair Applications

The connector can also form part of suitable glass railing and staircase systems.

Typical applications include:

Indoor Glass Railings
Suitable for staircases, mezzanines and interior guardrail structures.

Outdoor Glass Railings
SS304 is the preferred option where the connector faces normal outdoor moisture exposure.

Glass Staircases
The fitting can help connect fixed stair glass panels at corner positions.

For structural railing projects, however, the complete system design, glass specification and load requirements should always determine the final hardware selection.

SS201 and SS304 Stainless Steel Options

Two stainless steel grades are available.

SS201 Stainless Steel

SS201 offers a more economical option for suitable indoor environments with relatively low corrosion exposure.

It works best in dry interior applications where cost control is important.

SS304 Stainless Steel

SS304 provides better corrosion resistance and is the preferred option for most architectural glass installations.

In addition, we recommend SS304 for:

• Outdoor glass railings
• Balcony applications
• Humid environments
• Commercial architectural projects

For coastal or highly corrosive environments, buyers should confirm whether a higher corrosion-resistant stainless steel grade is required.

Suitable for 8–12mm Tempered Glass

The connector supports common architectural tempered glass thicknesses:

8mm

10mm

12mm

Before installation, confirm the exact glass thickness and connector specification.

In addition, installers should verify any required holes, cut-outs or glass processing dimensions before tempering the glass.

This helps avoid fitting problems during final installation.

Surface Finish Options

Standard finishes include:

Mirror Polished
Creates a bright reflective appearance that matches polished stainless steel hardware.

Satin
Provides a softer brushed stainless steel appearance for modern architectural projects.

Matte Black
Works well with contemporary black railing and partition hardware.

Other colors can also be customized according to project requirements.

For projects using several visible fittings, matching the connector finish with clamps, handrails and other hardware helps create a more consistent final appearance.

Fast Sample Dispatch

Standard samples can normally ship within 3 days.

This allows distributors, glass processors and project buyers to confirm:

• Glass compatibility
• Connector dimensions
• Material
• Finish
• Installation structure

before placing a bulk order.

Custom Options for Project Orders

For suitable B2B and project requirements, customization can include:

• Stainless steel grade
• Surface finish
• Color
• Selected dimensions
• Packaging
• OEM requirements

Customers can provide glass drawings or project specifications for confirmation before production.
