Frameless Folding Sliding Glass Door Hardware System

Toto Frameless Folding Sliding Glass Door Hardware System is a complete hardware solution designed for modern frameless glass doors that combine folding and sliding operation.

The system is designed for 10–12mm tempered glass and can support individual glass door panels weighing up to 90kg, depending on the final door dimensions, system configuration and installation conditions.

The main hardware components are manufactured from SS304 stainless steel, while the sliding track is made from hliníková zliatina. This combination provides reliable strength, durability and smooth operation while keeping the complete system practical for commercial glass door installations.

The folding and sliding design allows multiple glass panels to move along the track and fold together, helping create a wider opening while reducing the space required by conventional swing doors.

It is suitable for offices, hotels, restaurants, shopping malls, retail stores, meeting rooms and other commercial or architectural glass applications.

Špecifikácie produktu

Heavy-Duty 90kg Roller Capacity

The roller system is designed to support glass door panels weighing up to 90kg, making it suitable for larger and heavier frameless glass doors.

A properly configured roller and track system helps provide smooth sliding movement and reliable folding operation even when larger glass panels are used.

Before installation, the glass panel dimensions and weight should be confirmed to ensure that the selected hardware configuration is suitable for the project.

Designed for 10–12mm Tempered Glass

The system is suitable for:

10mm tempered glass
12mm tempered glass

Using 10–12mm tempered glass provides the rigidity required for larger frameless folding doors while maintaining a clean and modern architectural appearance.

Because the glass requires specific machining before tempering, the hole positions and dimensions should be confirmed before glass production.

SS304 Stainless Steel Hardware

The main fittings and accessories of the system are manufactured from SS304 stainless steel.

SS304 provides a good combination of strength, corrosion resistance and long-term durability, making it well suited for interior commercial glass door systems.

Depending on the door configuration, the hardware system can include:

• Válce
• Folding hinges
• Pivot fittings
• Sklenené svorky
• Connecting fittings
• Door stops
• Fasteners and installation accessories

Using matching hardware components helps improve system compatibility and simplifies sourcing for distributors, glass fabricators and project contractors.

Aluminum Sliding Track

The upper sliding track is manufactured from hliníková zliatina, providing a lightweight yet durable guide system for the folding glass door panels.

Aluminum is particularly suitable for long track profiles because it combines good dimensional stability with easier installation and transportation.

The track length and hardware configuration can be selected according to the number and width of the glass panels.

Folding and Sliding Operation

Unlike a conventional sliding glass door, this system allows multiple glass panels to slide along the track and fold together.

This design can create a much wider opening when the door system is fully opened.

Typical applications include:

• Office partitions
• Conference rooms
• Hotel interiors
• Reštaurácie
• Retail stores
• Nákupné centrá
• Commercial entrances
• Interior architectural glass partitions

Installation Technical Support

For B2B customers and project installations, we can provide technical installation guidance to help customers better understand the assembly sequence and hardware configuration.

Support can include guidance on:

• Hardware positioning
• Roller installation
• Track installation
• Folding panel arrangement
• Glass fitting installation
• System adjustment
• Final door alignment

This is especially useful for customers installing a folding glass door system for the first time.

Glass Drilling Drawings Available

Correct glass machining is critical for frameless folding glass door systems.

We can provide glass drilling and processing drawings according to the confirmed hardware configuration, helping glass factories prepare the tempered glass before installation.

The drawings can indicate important information such as:

• Polohy otvorov v skle
• Hole diameters
• Edge distances
• Hardware mounting positions
• Glass panel arrangement

The final glass dimensions and hardware configuration should be confirmed before the glass is tempered.

Complete Hardware Solution for B2B Projects

Rather than supplying only individual components, the system can be configured as a complete folding sliding glass door hardware solution.

For distributors, glass processors, contractors and project buyers, this helps reduce the risk of purchasing incompatible components from different suppliers.

We can support different project configurations according to:

Number of glass panels + door dimensions + glass thickness + opening direction + required track length.
