AISI 304 180 Degree Two Arm Spider Fitting 200mm for Glass Facades
180 Degree Spider Fitting for Architectural Glass Facades The 180 degree spider fitting is designed for point-supported architectural glass systems that require two glass fixing positions along a straight connection line. AOYU offers this 200mm stainless steel fitting for suitable glass facade and structural glazing applications. The fitting uses a two-arm configuration, with the arms […]
180 Degree Spider Fitting for Architectural Glass Facades
Acest 180 degree spider fitting is designed for point-supported architectural glass systems that require two glass fixing positions along a straight connection line. AOYU offers this 200mm stainless steel fitting for suitable glass facade and structural glazing applications.
The fitting uses a two-arm configuration, with the arms extending in opposite directions from a central mounting section. This inline arrangement distinguishes it from V-type and right-angle spider fittings.
As a result, architects and glazing contractors can select the appropriate connection geometry for their glass panel layout and supporting framework.
AISI 304 Stainless Steel Construction
AOYU manufactures this 180 degree spider fitting from AISI 304 stainless steel.
The material offers mechanical strength and corrosion resistance for architectural glass hardware applications. In addition, its metallic appearance complements exposed glass and steel structures.
The two-arm configuration provides a balanced, straight-line connection layout. Each arm forms a separate glass fixing position, while the central section connects to the supporting structure.
However, buyers should confirm the required surface finish and environmental conditions before placing an order.
Straight Two Arm Spider Fitting Design
180 Degree Inline Arm Configuration
Unlike the V-type spider fitting, this straight two arm spider fitting arranges its two glass fixing positions along a common axis.
This configuration is intended for glazing layouts where the fixing positions align on opposite sides of the central support.
Consequently, the fitting can be considered for suitable glass facade connection points requiring a straight two-arm arrangement.
Before ordering, contractors should verify the mounting positions and arm dimensions against the approved project drawing.
Two Glass Fixing Positions
The fitting provides two connection positions for compatible glass fixing components.
These components connect the glass panels to the spider arms and form part of the complete point-supported glazing assembly.
Meanwhile, the central mounting section transfers the connection to the supporting framework.
Therefore, installers must confirm the compatibility of the glass fixing hardware, mounting dimensions, and structural connections.
200mm Spider Fitting Dimensions
This product has a 200mm size designation.
For installation planning, customers should verify the exact dimensional references shown on the technical drawing rather than assuming that 200mm represents the overall length or center-to-center distance.
Important measurements include:
- Distance between the two glass fixing positions
- Central mounting hole dimensions
- Glass connection hole dimensions
- Arm profile and installation clearance
- Position of the supporting metal framework
These measurements help contractors coordinate the spider fitting with the glass panel layout.
Glass Holder and Fixing Compatibility
A two arm spider fitting works together with compatible glass fixing holders and suitable structural mounting hardware.
However, the correct fixing assembly depends on the selected glass thickness, hole preparation, and connection requirements.
Before purchasing, customers should confirm the glass holder model, connection dimensions, and required accessory quantities.
Furthermore, the complete assembly must meet the project's structural design requirements.
AOYU recommends reviewing the technical drawings before confirming bulk orders.
Applications of 180 Degree Glass Spider Fittings
Point-Supported Glass Facades
Architectural glass facades use spider fittings to create mechanical connections between glass panels and structural frameworks.
The straight two-arm design provides an alternative to angled spider fittings when the project requires inline fixing positions.
Glass Curtain Wall Systems
Suitable point-supported curtain wall systems may use 180 degree spider fittings as part of their connection arrangements.
The fitting must match the structural frame, glass panel geometry, and specified fixing hardware.
Architectural Glazing Projects
Other architectural glazing structures may also require two-point inline connections.
Nevertheless, engineers should evaluate the complete installation, including the supporting structure, glass configuration, and applied loads.
Technical Specifications
| Specificație | Details |
|---|---|
| Denumire produs | 180 Degree Spider Fitting |
| Product Type | Straight Two Arm Glass Spider |
| Material | AISI 304 Stainless Steel |
| Size Designation | 200mm |
| Arm Configuration | Two Arms, Inline |
| Glass Fixing Positions | 2 |
| Aplicații | Glass Facades and Point-Supported Glazing |
| Manufacturer | AOYU Hardware |
Technical Note: The exact product model, dimensions, compatible glass holder, glass thickness range, and load capacities should be confirmed against the manufacturer's technical drawing before final specification.
Installation and Structural Considerations
First, installers should confirm that the straight-arm configuration matches the intended glass connection layout.
Next, they should verify the central mounting position and supporting framework.
In addition, the selected glass fixing components must be compatible with the glass panel and required hole preparation.
Finally, a qualified project engineer should assess the complete glazing assembly and confirm its structural suitability.
AOYU Spider Fitting Manufacturer and Wholesale Supply
AOYU manufactures architectural glass hardware for wholesalers, distributors, facade contractors, glass processors, and construction project buyers.
Our product range includes different spider fitting configurations for point-supported glazing systems.
Moreover, AOYU supports OEM and project-specific hardware inquiries, including discussions about dimensions, materials, and surface finishes.
For wholesale quotations, please provide the required product model, order quantity, glass specifications, and relevant technical drawings.
Our team can then review the requirements and discuss the appropriate product configuration.
Contact AOYU for 180 degree spider fitting specifications, OEM customization, and wholesale quotations.
